Other Crystals

The crystals of Yttrium-Aluminum Garnet (YAG) doped with three-valence vanadium V3+ in tetrahedral position is relatively new material for passive Q-switching. V:YAG has working as efficient Q-switch for lasers operating in the 1.0~1.5 µm region. The absorption band between 1.0~1.5 µm is attributed to 3A2 →3T2 transition of V3+ ion in tetrahedral position of garnet lattice. Concentration of V3+ in tetrahedral position is controlled by growth and annealing conditions. The efficient Q-switching of lasers operating at both 1.064 and 1.3 micron has been obtained with a number of active mediums such as Nd:YAG, Nd:YVO4, Nd:KGd(WO4)2 under flashlamp and laser diode pumping.

Zoolied has been devoted to producing optical components for many years. It's always the reliable choice for consumers. We can offer a variety of Crystal Optics such as YVO4 Crystal Yttrium Vanadate, CaF2 Crystals Calcium Fluoride IR Optics, Nd YAG laser crystals, Diffusion bouding crystals, Erbium Laser Glass and Ti:Sapphire Crystal. There are three kinds of Passive Q-switch Crystals that you can choose. They are Passive Q-switch Cr4+:yag Crystals, Passive Q-switch V:yag Crystals and Passive Q-switch Co2+:mgal2o4 Crystal Co:spinel. If you have other requirements, we also can make customized products.

Zoolied Crystals Lists
ND:YAG	Ce:LuAG	Yb∶KYW	YIG
Cr:YAG	Ho:LUGG	Iceland crystal	DKDP
YV04	Nd:LuAG	Mg0∶LiNbO3	YAB
MD:YV04	Tm:Ho:YLF	Ho∶YV04	Mg0:LiTa03
Yb:YAG	Nd:YAP	Nd∶YSAG	Tm:KYW
ND∶GdV04	V:YAG	Er∶YLF	Fe:LiNb03
Nd:YLF	SGGG	Nd:GYSGG	RTP
Ho∶YAG	LiL03	Er∶KGW	KYW
BBO	Nd:Ce:YAG	ND:GYSAG	TSAG
LBO	BLO	Quartz	KTA
KTP	Er:Yb:YAB	Tm∶YVO4	GYSGG
TGG	Er:YSGG	GGG	Cr:Nd:YAG
LiNbO3	Ho:YAP	Nd∶GSGG	Yb:YAB
CaF2	YSGG	KDP	Tb:YLF
LiTa03	HGTR-KTP	Ti∶sapphire	Ho∶YLF
a-BB0	Er:YAP	YLF	YSGG
Co∶MgAl204	LiF	Yb∶YLF	MgF2
JGS1	Er:YAG	Yb∶CaF2	PMN-PT
GdV04	Cr:LiCAF	LYSO	Dy:YLF
Tm∶YLF	SrWO4	LiGa02	Nd:KGW
Pr∶YLF	GdSc03	Tm∶YAP	BiB0
Yb∶KGW	Cr:GSGG	KGW	Er:Caf2
Sapphires	TGGG	Cr∶Er∶YSGG	Ce:YAG
YLF	ADP	Cr∶LiSAF	CBN
YAG	LiSAF	LiCAF	PPKTP
