KTP Crystal Potassium Titanyl Phosphate

$220 - 260.8 /Piece/Pieces

Color:

Plug type:

Other

option:

NLO crystals
KTP Crystal
Nd-doped lasers
Potassium Titanyl Phosphate

Contact Now

Sample: $1000.00 /Piece/Pieces, 1 Piece/Piece...Buy Sample

Share: Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

Overview

Product Attributes

Model No.: ZLY895

Brand: ZOOLIED

Material: Crystal

Shape: Cuboid/Rod/Cube

Dimension: 2-20mm

Length: 10-200mm

Flatness: λ/8 -λ/10

Parellelism: 10"-20"

S/D: 20/10 - 40/20

Chamfer: Protective Chamfer

Bevel: Protective bevel as needed

Coating type: AR

Supply Ability & Additional Information

Packaging: Standard Package

Productivity: 8000000

Transportation: Ocean,Land,Air,Express

Place of Origin: Changchun

Supply Ability: 8000000

Certificate: ISO9001

HS Code: 90019090

Payment Type: L/C,T/T,D/P,Paypal

Incoterm: FOB,CFR,CIF,EXW,FCA

Packaging & Delivery

Selling Units:: Piece/Pieces

Single package size:: 20cm*20cm*20cm

Single gross weight:: 1kg

Package Type:: Standard Package

Picture Example:

KTP crystals is the most commonly used material for frequency doubling of Nd-doped lasers, particularly at the low or medium power density.It is widely used for frequency mixing to generate Red/Green/Blue output, and for OPO and OPA to generate visible to mid-infrared tunable output. It is also used for many E-O devices such as Q-switches and E-O modulators.

Advantages:

• Large nonlinear optical coefficient

• Wide angular bandwidth and small walk-off angle

• Broad temperature and spectral bandwidth

• High Electro-Optics(E-O) coefficient and low dielectric constant

• Non-hygroscopic, chemically and mechanically stable

KTP's Applications：

• Frequency Doubling (SHG) of Nd-doped Lasers for Green/Red Output

• Frequency Mixing (SFM) of Nd Laser and Diode Laser for Blue Output

• Parametric Sources (OPG, OPA and OPO) for 600nm - 4500nm Tunable Ouptut

• E-O Modulators, Optical Switches, Directional Couplers

• Optical Waveguides for Integrated NLO and E-O Devices

Zoolied is a leading Crystal Optics supplier. We are responsible for all of consumers. Our company can offer a variety of Crystal Optics such as KTA Crystal Potassium Titanyle Arsenate, KTP Crystal Potassium Titanyl Phosphate, CaF2 Crystals Calcium Fluoride IR Optics, Nd YAG laser crystals, Diffusion bouding crystals, Erbium Laser Glass and Ti:Sapphire Crystal.
Photobank

Zoolied Crystals Lists
ND:YAG	Ce:LuAG	Yb∶KYW	YIG
Cr:YAG	Ho:LUGG	Iceland crystal	DKDP
YV04	Nd:LuAG	Mg0∶LiNbO3	YAB
MD:YV04	Tm:Ho:YLF	Ho∶YV04	Mg0:LiTa03
Yb:YAG	Nd:YAP	Nd∶YSAG	Tm:KYW
ND∶GdV04	V:YAG	Er∶YLF	Fe:LiNb03
Nd:YLF	SGGG	Nd:GYSGG	RTP
Ho∶YAG	LiL03	Er∶KGW	KYW
BBO	Nd:Ce:YAG	ND:GYSAG	TSAG
LBO	BLO	Quartz	KTA
KTP	Er:Yb:YAB	Tm∶YVO4	GYSGG
TGG	Er:YSGG	GGG	Cr:Nd:YAG
LiNbO3	Ho:YAP	Nd∶GSGG	Yb:YAB
CaF2	YSGG	KDP	Tb:YLF
LiTa03	HGTR-KTP	Ti∶sapphire	Ho∶YLF
a-BB0	Er:YAP	YLF	YSGG
Co∶MgAl204	LiF	Yb∶YLF	MgF2
JGS1	Er:YAG	Yb∶CaF2	PMN-PT
GdV04	Cr:LiCAF	LYSO	Dy:YLF
Tm∶YLF	SrWO4	LiGa02	Nd:KGW
Pr∶YLF	GdSc03	Tm∶YAP	BiB0
Yb∶KGW	Cr:GSGG	KGW	Er:Caf2
Sapphires	TGGG	Cr∶Er∶YSGG	Ce:YAG
YLF	ADP	Cr∶LiSAF	CBN
YAG	LiSAF	LiCAF	PPKTP
