What is a Silicon Wafers? Monocrystalline silicon wafer is abbreviated as silicon wafer, which is a round sheet material whose atoms are artificially rearranged to be a high-purity semiconductor material with crystal orientation. Semiconductor Thin Si Wafers selection: Silicon wafer is a thin slice of semiconductor material, which is widely used in the production of electronic and micromechanical equipment. They are characterized by many parameters that affect their suitability and performance for selected tasks. When selecting silicon wafers, the main parameters that need to be considered are the following aspects: Wafer diameter, Type, Crystallographic Orientation, Dopant, Growth Method, Material, Resistivity, Thickness, Polish and Alignment Fiducial.
Zoolied offers a variety of optical Glass Wafers, such as Dummy Silicon Wafers, Jgs1 Wafers, and K9 Wafers, and Bk7 Wafers. ZOOLIED provides multiple anti-reflection coating options and also provides uncoated optical glass wafers. Looking for ideal optical si wafers and Ge Wafers Manufacturer & supplier? We have a wide selection at great prices to help you get creative. All the optical glass wafers are quality guaranteed. Zoolied is China Origin Factory of optical Wafers. If you have any question, please feel free to contact us.
Note: Please pay attention to your email at any time after inquiring, we will send you the quotation by email.
Zoolied Standard Silicon Wafer | |||||||
Diameter | 2" | 3" | 4" | 5" | 6" | 8" | 12" |
Grade | Prime/ Test/ Dummy | ||||||
Growth Method | CZ/FZ | ||||||
Orientation | < 100 > , < 111 > , < 110 > | ||||||
Type/Dopant | P/Boron , N /Phos, N /As, N /Sb | ||||||
Thickness (um) | 279 | 380 | 525 | 625 | 675 | 725 | 775 |
Thickness Tolerance | Standard ± 25μm | ||||||
Resistivity | 0.001 - 10,000ohm-cm | ||||||
Surface Finished | DSP,SSP | ||||||
TTV (um) | Standard < 10 um | ||||||
Bow/Warp (um) | Standard <40 um | ||||||
Particle | Specified by customer |
