DSP 50.8mm 500um >10000Ω.cm Intrinsic Silicon wafer
$25≥50 Piece/Pieces
Payment Type:
L/C,T/T,D/P,Paypal
Incoterm:
FOB,CFR,CIF,FCA
Min. Order:
50 Piece/Pieces
Transportation:
Air
Sample: $50.00 /Piece/Pieces, 10 Piece/Pieces...Buy Sample
Share: Chat Now
Product Description
Overview
Product Attributes

Model No.: ZLY295

Brand: Zoolied

place of origin: China

Type/Dopant: P/B Or N/Ph Or Intrinsic

TTV&Bow: Spesified By Customer

Diameter: 1" 2" 3" 4" 6" 8" 12"

Thickness: 0.1-2.0mm

Growth: Fz/Cz

orientation: <100><110><111>

Resistivity: 0.01~10,000 Ohm-Cm

Surface Finish: Ssp Or Dsp

Warp: Spesified By Customer

particles: Spesified By Customer

Supply Ability & Additional Information

Packaging: Standard

Productivity: 9999999999

Transportation: Air

Place of Origin: Changchun

Supply Ability: 9999999999pcs/year

Certificate: ISO

HS Code: 3801010

Payment Type: L/C,T/T,D/P,Paypal

Incoterm: FOB,CFR,CIF,FCA

Packaging & Delivery
Selling Units:
Piece/Pieces
Single package size:
20cm*20cm*20cm
Single gross weight:
1kg
Package Type:
Standard
Picture Example:

Zoolied's Silicon Wafers are diverse and have a wide range of applications, from non-polished wafers to epitaxial silicon wafers up to 300 mm in diameter. Silicon wafers are made of single crystal silicon ingots made using the Czochralski method (CZ) or floating zone method (FZ). Since silicon wafers are critical to the function of semiconductor components, many different processes can be used to ensure the best material properties for each customer's application. Of particular importance is the specific application of the dopant and the cooling curve of the Thin Si Wafers. The surface condition of the wafer is also customized for specific applications. It ranges from simple slicing to double-sided and epitaxial surface polishing.


Zoolied offers a variety of optical Glass Wafers, such as Dummy Silicon WafersJgs1 Wafers, and K9 Wafers, and BK6 wafers. Zoolied provides multiple anti-reflection coating options and also provides uncoated optical glass wafers. Looking for ideal optical si wafers and Ge Wafers Manufacturer & supplier? We have a wide selection at great prices to help you get creative. All the optical glass wafers are quality guaranteed. Zoolied is China Origin Factory of optical Wafers. If you have any question, please feel free to contact us.

Note: Please pay attention to your email at any time after inquiring, we will send you the quotation by email.

Zoolied Standard Silicon Wafer
Diameter 2" 3" 4" 5" 6" 8" 12"
Grade Prime/ Test/ Dummy
Growth Method CZ/FZ
Orientation < 100 > , < 111 > , < 110 >
Type/Dopant P/Boron , N /Phos, N /As, N /Sb
Thickness (um) 279 380 525 625 675 725 775
Thickness Tolerance Standard ± 25μm
Resistivity 0.001 - 10,000ohm-cm
Surface Finished DSP,SSP
TTV (um) Standard < 10 um
Bow/Warp (um) Standard <40 um
Particle Specified by customer



Silicon wafers 1


silicon wafers2
