Detection and Polishing Suppression of Subsurface Damage in High-Power Lenses
2026-7-13
In high-power lasers (>1kW), lenses with intact coatings may suddenly crack and experience a sharp drop in lifespan. The culprit is often not surface defects, but rather subsurface damage (SSD) hidden beneath the surface—a network of microcracks left by grinding. Under intense light, this causes nonlinear thermal absorption, leading to stress concentration and cracking.
1. Where Does SSD Come From?
1.1 Crack Formation Mechanism
When free abrasive (diamond/boron carbide) is rolled onto an optical surface, the following are simultaneously generated:
Radial cracks: Extend vertically downwards, forming the main body of the SSD.
Transverse cracks: Propagate parallel to the surface, prompting brittle fracture and removal of the material.
Classic engineering empirical formula: SSD depth ≈ 3~4 × surface roughness PV value. If the peak-to-valley difference (PV) of the surface after fine grinding is 5μm, then there must be a crack layer buried 15~20μm deep beneath it.
1.2 Surface Artifacts of Traditional Polishing
Traditional asphalt polishing has an extremely low rate (<0.5μm/h), and the soft polishing layer presses the abrasive into cracks, forming a "redeposited layer" containing impurities from the polishing fluid. While the surface appears perfect from an interferometer perspective (PV<λ/10), the cracks beneath the cross-section are filled with metal ions (Ce³⁺, Fe³⁺)—this is precisely the root cause of laser absorption heating.
2. Three Engineering-Level Testing Methods
3. Two-Step Deterministic Removal Process
3.1 Magnetorheological Polishing (MRF): Highly Efficient Crack Layer Removal
MRF utilizes a magnetic field to harden the polishing slurry, forming a flexible ribbon that removes material with shear force. The vertical pressure is extremely low, preventing the induction of new cracks.
Key Parameters:
Single-pass removal thickness ≥ SSD maximum depth + 5μm margin (e.g., if measured at 18.7μm, then removal ≥ 24μm).
Removal rate approximately 5μm/min, significantly more efficient than traditional polishing.
3.2 Ion Beam Figuring (IBF): Atomic-Level Surface Cleaning
Ar⁺ ion physical sputtering removes the final 1–2 μm of the surface layer, offering zero mechanical pressure and thus introducing absolutely no new SSD. This process also eliminates residual magnetic particles and metal ions left by MRF, thereby purifying the surface.
3.3 Comparison of Results
Conclusion: The combined process increases the damage threshold by 180%, and SSD is compressed to the near-atomic level.
4. Mass Production Recommendations
MRF+IBF labor costs are relatively high (approximately ¥800/hour). For mass production, we recommend a tiered approach:
High-power (>100W)/Lithography Objectives: Forced MRF (30μm) + IBF full process. The cost per unit increases by approximately ¥2,000, but lifespan increases from 200h to 2000h, resulting in a 40% reduction in Total Cost of Ownership (TCO).
Low-power (<1W)/Imaging System: Only MRF removes 15μm particles, no IBF required, cost is controllable.
Engineering Warning: Regularly replace the MRF circulating filter (pore size ≤0.2μm) to prevent large, broken particles (>0.5μm) from entering the polishing fluid and causing secondary scratches; otherwise, SSD performance will increase instead of decrease.
5. Conclusion
A bright surface does not equate to an undamaged one. The understanding and control of subsurface damage (SSD) represent the watershed moment that transitions optical fabrication from experience-based polishing to deterministic manufacturing. The combined process route integrating MRF-based deterministic removal with IBF-based atomic-level cleaning has become an essential requirement for the mass production of high-end optical systems, including high-power lasers and lithography tools—as it directly determines whether a lens survives for 200 hours or 2,000 hours of service.
