What is the function of Powell lens?
Powell Optical Glass Beamsplitter are currently widely used in industrial and research applications, where uniform intensity distribution is essential, because lasers are used as illumination sources, or, for example, in material processing, when the entire area irradiated by the laser must be processed to be uniform and equal The way. Powell lenses will produce a very uniform line of illumination for a variety of machine vision applications; from biomedical and automotive assembly to chocolate chip cookie production.
Note: Please pay attention to your email at any time after inquiring, we will send you the quotation by email.
| Zoolied Standrad Powell Lens | ||||||
| Product Model | Incident Beam(mm) | Fan Angle(°) | Diameter(mm) | Height(mm) | Material | Coating(nm) |
| PW1GB-05 | 1 | 5 | 9 | 8 | K9 | no coating |
| PW1GB-10 | 1 | 10 | 9 | 8 | K9 | no coating |
| PW1GB-15 | 1 | 15 | 9 | 8 | K9 | no coating |
| PW1GB-20 | 1 | 20 | 9 | 8 | K9 | no coating |
| PW1GB-30 | 1 | 30 | 9 | 8 | K9 | no coating |
| PW1GB-40 | 1 | 40 | 9 | 8 | K9 | no coating |
| PW1GB-45 | 1 | 45 | 9 | 8 | K9 | no coating |
| PW1GB-60 | 1 | 60 | 9 | 8 | K9 | no coating |
| PW1GB-75 | 1 | 75 | 9 | 8 | K9 | no coating |
| PW1GB-90 | 1 | 90 | 9 | 8 | K9 | no coating |
| PW1GB-110 | 1 | 110 | 9 | 8 | K9 | no coating |
| PW2GB-4 | 2 | 4 | 9 | 8 | K9 | no coating |
| PW2GB-30 | 2 | 30 | 9 | 8 | K9 | no coating |
| PW2GB-60 | 2 | 60 | 9 | 8 | K9 | no coating |
| PW2GB-70 | 2 | 70 | 9 | 8 | K9 | no coating |
| PW2.5GB-30 | 2.5 | 30 | 9 | 8 | K9 | no coating |
| PW3GB-10 | 3 | 10 | 9 | 8 | K9 | no coating |
| PW3GB-15 | 3 | 15 | 9 | 8 | K9 | no coating |
| PW3GB-20 | 3 | 20 | 9 | 8 | K9 | no coating |
| PW3GB-30 | 3 | 30 | 9 | 8 | K9 | no coating |
| PW3GB-35 | 3 | 35 | 9 | 8 | K9 | no coating |
| PW3GB-40 | 3 | 40 | 9 | 8 | K9 | no coating |
| PW3GB-45 | 3 | 45 | 9 | 8 | K9 | no coating |
| PW3GB-60 | 3 | 60 | 9 | 8 | K9 | no coating |
| PW3GB-70 | 3 | 70 | 9 | 8 | K9 | no coating |
| PW3GB-75 | 3 | 75 | 9 | 8 | K9 | no coating |
| PW3GB-90 | 3 | 90 | 9 | 8 | K9 | no coating |
| PW3GB-110 | 3 | 110 | 9 | 8 | K9 | no coating |
| PW4GB-22 | 4 | 22 | 9 | 8 | K9 | no coating |
| PW4GB-30 | 4 | 30 | 9 | 8 | K9 | no coating |
| PW4GB-90 | 4 | 90 | 9 | 8 | K9 | no coating |
| PW5GB-10 | 5 | 10 | 9 | 8 | K9 | no coating |
| PW5GB-30 | 5 | 30 | 9 | 8 | K9 | no coating |
| PW5GB-35 | 5 | 35 | 9 | 8 | K9 | no coating |
| PW5GB-40 | 5 | 40 | 9 | 8 | K9 | no coating |
| PW5GB-45 | 5 | 45 | 9 | 8 | K9 | no coating |
| PW5GB-55 | 5 | 55 | 9 | 8 | K9 | no coating |
| PW5GB-60 | 5 | 60 | 9 | 8 | K9 | no coating |
| PW5GB-70 | 5 | 70 | 9 | 8 | K9 | no coating |
| PW5GB-75 | 5 | 75 | 9 | 8 | K9 | no coating |
| PW5GB-90 | 5 | 90 | 9 | 8 | K9 | no coating |
